Luxlite Dimmable Triac Drivers
Luxlite dimmable Triac drivers are perfect for dimming 24V LED lighting, offering compatibility with both trailing edge and leading edge dimming systems. They are designed to handle loads from 0 to 75W, making them ideal for a variety of residential, office, and retail applications.
These power supplies provide seamless dimming for constant voltage 24V LEDs, directly through mains dimming. By pairing the Luxlite power supply with either a trailing edge or leading edge dimmer, you gain precise control over lighting levels. Enjoy tidy, efficient, and simple Triac dimming to enhance the ambiance of your space.
For optimal performance, we recommend loading the power supply close to its maximum capacity to ensure the most effective dimming control.
Note: This driver is specifically designed for dimming mains voltage single-color LED lights. If you’re using a controller, a dimmable driver is not needed, as the controller manages the low voltage dimming.
| Specification | Details |
|---|---|
| Output Voltage | 24V |
| Output Current | Up to 3.12 |
| Rated Power | Up to 75 Watts |
| Dimming Mode | TRIAC CV |
| Input Voltage Range | AC220-240V |
| Input Frequency | 50/60Hz |
| Power Factor | > 0.9 |
| Inrush Current | < 75A |
| Min. Operating Temperature | -20°C |
| Max. Operating Temperature | 45°C |
| Overload Protection | Yes |
| Short Circuit Protection | Yes |
| Over Voltage Protection | Yes |
| Electrical Safety Class | II |
| Guarantee | 5 Years |
| Dimmable | Yes |
| Application Environment | Indoor |
| Body Material | Plastic |
| Ingress Protection (IP) | 20 |
| Constant Voltage | CV |
| Output Current Type | DC |
| Dimming Range Min. – Max (%) | 15-90% |
| Brand | Luxlite |
